Wired for Success: Avoiding Common Electrical Errors in the Field

July 4, 2025 by
Wired for Success: Avoiding Common Electrical Errors in the Field
LCO Technologies, Mackenzie Williams

Introducing Modern Electronics to the Field

Out in the field, most systems run on tried-and-true 24V DC setups: simple, reliable, and familiar. These systems typically operate in a basic on-or-off mode. They’re effective, but not built for fine-tuned control.

Now, newer technology like Variable Frequency Drives (VFDs) is offering a different approach. With a VFD, you’re not just switching something on. You’re gaining precise control over how it runs.

Let’s take a closer look at how that changes things.


Not On or Off: Think Dimmer Switch

Traditional systems are like flipping a light switch. The equipment is either fully on or completely off, often wasting energy and creating wear through constant power cycling.

Now imagine using a dimmer switch instead. You slide it to get exactly the level of light you want; no more, no less. That’s how a VFD works. It adjusts motor speed smoothly and precisely, depending on demand.

In the CROSSFIRE Chemical Injection Pump, this means the system speeds up or slows down in real time, based on how much chemical is needed. The result? Even dispersion, no waste, and a big reduction in overheating or stress on components.


Smart Tech, Smarter Performance

This modern control method comes with significant advantages, but also introduces some complexity. Understanding a few key electrical concepts will help ensure reliable field performance.

Harmonics

Think of harmonics as unwanted electrical echoes. When a VFD rapidly switches power to control motor speed, it creates "ripples" in the electrical signal. These harmonics can interfere with nearby electronics and become more pronounced on long cable runs.

Resistance

All wires have resistance, or electrical friction. The longer or thinner the wire, the more resistance it introduces. Too much resistance means voltage drops before it reaches the controller or motor, which can cause faults, reduce performance, or prevent operation altogether.


Why It Matters in the Field

Unlike traditional chemical injection systems that simply pulse chemicals in on-off bursts, CROSSFIRE provides continuous injection, ensuring even dispersion and stable site operation. There are no sudden power surges or inrush currents, thanks to the brushless motor and VFD control.

Here’s how it all fits together in a typical install.

ComponentKey Cable RunWhat to Watch For
Solar panelTo charger (max 80 ft)Use thick wire (AWG 10) and control surge from open circuit voltage
Battery boxTo controller (max 60 ft)Keep it short to avoid voltage drop
ControllerTo pump (3-phase, max 60 ft)Longer runs increase harmonics and reduce motor efficiency
Motor leadsHigh-frequency switchingUse shielded wire if needed to reduce electrical noise


Most Common Installation Errors to Avoid

MistakeWhy It’s a Problem
Too long or wrong-size wireCauses voltage drop, high current draw, and controller faults
Loose terminal screwsLeads to high resistance, triggering fault codes or shutdowns
Surge spike from solar panelsCan instantly damage the CROSSFIRE controller
Direct resistor install on controllerBreaks fragile terminals and may void the warranty
Improper RS-485 wiring or groundingDisrupts Modbus communication or causes noise interference


Wrap-Up: Smart Wiring for a Smart System

The CROSSFIRE system is designed to be reliable and efficient but it relies on smart installation to reach its full potential. By respecting cable lengths, using the right wire gauge, and avoiding common electrical mistakes, operators can get the best performance out of every pump, every time.

Need help on a specific site or setup? The team at LCO Technologies is always here to guide you through best practices for layout, wiring, or troubleshooting.

Find more resources on our Support Page.
